RXS500DSI SINGLE SPINDLE
Sku: RXS500DSI SINGLE SPINDLE
Vendor: Cybertech
Status: Stocking
Contact
Axis accelerations of up to 3g are attained. The RXS500DSI2 was designed as a dual-spindle machine, so that in the case of production with only two tools (e.g. impeller machining) the non-productive times for the tool changes are omitted entirely. The parts change can be carried out while the spindles are running.
RÖDERS RXS500DSI SINGLE SPINDLE
Highly dynamic 5-axis machines
- Lightweight construction
- Stronger motors for the greatest possible dynamics
- Accelerations ranging to over 3 g
- The options of the RXP series, such as automatic tool measurement, emulsion coolant and lead-through for inner tool cooling, are available for both machine types Special chucks for direct clamping of e.g. impellers can be integrated into the table.
Technical data | |
---|---|
Machining range | 450 mm x 370 mm x 155 mm |
Swivelling range | +/-115 degrees |
Rotation range | Almost unlimited |
Table size | 200 mm |
Workpiece weight | Max. 10 kg |
Feed | 0-42,000 mm/min |
Milling spindle (standard) | 42,000 rpm, 14 kW, HSK E40, vector-controlled for short acceleration times, maximum tool diameter 16 mm (others on request) |
Tool changer | 26 (can be loaded during machining) optional 54 places (chain changer – can be loaded during machining) |
Tool measuring laser | Integrated in tool changer |
Chip disposal | With scraping conveyor into chip trolley |
Machine weight | ~6.0 t |
Required space | W 3110 mm x L 2350 mm x H 2320 mm |
